DESCRIPTION
Freiburg electric tram opened in 1901 and from that date it has been continuosly in service. The tram system was constantly extended; last extensions opened in 1983, 1985, 1994, 1997, 2002, 2004, 2006 and 2014.
The current network consists in 5 lines.
(last modified February 19, 2017 )
HISTORY
datesection nameline
1901initial electric tram section--
1983Technisches Rathaus-Paduaallee--
1983network voltage converted fro 600 V DC to 750 V DC--
1985Paduaallee-Landwasser--
1994Bissierstrasse-Haid--
1997Am Lindenwaldle-Rieselfeld--
2002Am Lindenwaldle-Pressehaus--
2004Pressehaus-Johanneskirche--
2006Heinrich von Stephan Strasse-Vauban--
15-03-2014Reutebachgasse-Zahringen/Gundelfinger Strasse--
(last modified February 19, 2017 )
TECHNICAL DATA
Single line length (Km)
Line 1:9.9
Line 2:6.2
Line 3:9.2
Line 4:8.3
Line 5:12.4
Single line stops
Line 1:22
Line 2:19
Line 3:21
Line 4:20
Line 5:30
Single line avg. distance (km)
Line 1:0.45
Line 2:0.35
Line 3:0.45
Line 4:0.45
Line 5:0.45
Total track length (km)
33.8
Total network stops
73
Avg. stop net distance (km)
0.5
Type
steel wheels
Current/Voltage
750 V DC overhead
Type of guide/gauge
metric gauge rails (1000 mm)
Vehicles builder
DUEWAG,SIEMENS
Model
GT8K,GT8N,GT8Z,Combino Basic,Combino Advanced
Operator
FREIBURGER VERKEHRS AG
(last modified February 19, 2017 )
This image is shown smaller (800 x 800 pixels) than its maximum size (1200 x 1196 pixels)
Please click on the map to enlarge it to its maximum size


lrt-tram - freiburg; By Strassenbahn Freiburg_Liniennetz_1.png: Grauer Elefant derivative work: Pechristener [CC BY-SA 3.0 (http://creativecommons.org/licenses/by-sa/3.0)], via Wikimedia Commons
