DESCRIPTION
Zaragoza tram opened in 1885 (initial horse tram) and it was electrified in 1902. The original tram network was closed in 1976.
A modern LRT/tram line opened on 19-04-2011 (Gran Via-Mago de Oz); it was extended in 2012 (Gran Via-Plaza Espana; Plaza Espaaa-Plaza del Pilar/Murallas) and 2013 (Plaza del Pilar/Murallas-Avenida de la Academia). The new tram runs north-south connecting Valdespartera (Mago de Oz) with Parque Goya (Academia), passing through the city centre; along a short central section is feeded by onboard supercapacitors (without overhead electric power supply).
The tram serves the railway network (Fernando el Catolico-Goya stop); two important park&ride facilities are located along the track (at Valdespartera and close to La Chimenea stop); another interchange stop is located at the railway station.
(last modified February 19, 2017 )
HISTORY
datesection nameline
1885initial horse tram opening--
1902electrification completed--
1976tram network closure--
19-04-2011Gran Via-Mago de Oz--
04-04-2012tram/railway at new underground Cercanías stop--
31-10-2012Gran Vía-Plaza España--
20-12-2012Plaza España-Plaza del Pilar/Murallas--
26-03-2013Plaza del Pilar/Murallas-Avenida de la Academia--
(last modified February 19, 2017 )
TECHNICAL DATA
Single line length (Km)
--
Single line stops
--
Single line avg. distance (km)
--
Total track length (km)
12.8
Total network stops
25
Avg. stop net distance (km)
0.55
Type
steel wheels
Current/Voltage
750 V DC overhead
Type of guide/gauge
standard gauge rails (1435 mm)
Vehicles builder
CAF
Model
Urbos 3
Operator
SEM LOS TRANVIAS DE ZARAGOZA, SA
Note
along Murallas-Gran Via section tramcars feeded by onboard supercapacitors, without catenary
(last modified February 19, 2017 )
this map is shown here at its maximum resolution (800 x 833)


lrt-tram - zaragoza; By OpenStreetMap contributors, user:ecelan & user:Robot8A [CC BY-SA 2.0 (http://creativecommons.org/licenses/by-sa/2.0)], via Wikimedia Commons
