DESCRIPTION
Milan tram service (initially operated as horse tram) opened in 1876 (Milan-Monza) and 1877 (Milan-Saronno); the electrification was completed in 1901. The tram network was continuously extended during the years, becoming one the most extended in Europe; the maximum development of the network was reached in 1940 (more than 300 km).
Some important reductions occurred in the successive decades, due also to the insertion of the new metro network, but differently from other towns the tram operations never had complete or massive interruptions. The current length of the tram system is about 170 km.
In the last years the tram network has been renewed and modernized by the adoption of a modern low floor rolling stock and by the addiction of new modern LRT lines ("metrotranvie") characterized by a relevant lane segregation in many sections and/or right-of-way at the grade level crossings. These innovations have increased the average commercial speed and the system efficiency.
The first of the so-called "metrotranvie" (Line 7 or Metrotranvia Interperiferica Nord: from Mattei-Bicocca to Zara-Lagosta) started its operations at the end of year 2002; it was extended in 2003 from Lagosta to Procaccini. Line 7 interchanges with metro M1 (at Precotto), with M3 (at Zara) and with driverless metro M5 (at Zara, Marche, Istria, Ca' Granda and Bicocca).
Line 4 or "Metrotranvia Nord" (from Parco Nord to Largo Cairoli) and Line 15 or "Metrotranvia Sud" (from Piazza Fontana to Rozzano) opened at the end of 2003. Line 4 interchanges with metro M3 (at Maciachini) and metro M2 (at Lanza); Line 5 interchanges with M1 (at Piazza Venezia), with M2 and M3 (at Stazione Centrale) and with driverless metro M5 (at Marche, Zara, Istria and Ca' Granda).
Line 31 or "Metrotranvia Milano-Cinisello Balsamo" opened on 7 December 2008, connecting Lagosta to Cinisello Monte Ortigara; it shares part of its track with Line 7/Metrotranvia Interperiferica Nord. It interchanges with metro M5 (at Bicocca, Ponale and Bignami).
(last modified February 19, 2017 )
HISTORY
datesection nameline
1876first horse tram line:Milan-Monzatram
1877second tram line:Milan-Saronnotram
1878network extensiontram
1879network extensiontram
1880network extensiontram
1881network extensiontram
1901electrification completedtram
1910network extensiontram
1931network extensiontram
1939network reached its peak lenght of about 300 kmtram
1957tram sections removal in the city centre due to metro constructiontram
1964outer extension to Taliedotram
1969outer extension to Gratosogliotram
1970network contraction due to the elimination of duplicated routestram
1981tram section opened along via Largatram
1992Gratosoglio-Rozzano extension;some section closed due to Metro M3 constructiontram
07-12-2002Procaccini-BicoccaMetrotranvia Interperiferica Nord
07-07-2007Bicocca-PrecottoMetrotranvia Interperiferica Nord
07-12-2003Piazzale Maciacchini-Niguarda Parco NordMetrotranvia Nord
07-12-2003Porta Ludovica-AbbiategrassoMetrotranvia Sud
07-12-2008Piazzale Lagosta-CiniselloMetrotranvia Milano-Cinisello
(last modified February 19, 2017 )
TECHNICAL DATA
Single line length (Km)
Tram:152
Metrotranvia Nord:7.1
Metrotranvia Sud:10.5
Metrotranvia Interperiferica Nord:7.1
Metrotranvia Milano-Cinisello Balsamo:8.7
Single line stops
Tram:--
Metrotranvia Nord:19
Metrotranvia Sud:30
Metrotranvia Interperiferica Nord:27
Metrotranvia Milano-Cinisello Balsamo:25
Single line avg. distance (km)
Tram:--
Metrotranvia Nord:0.4
Metrotranvia Sud:0.35
Metrotranvia Interperiferica Nord:0.3
Metrotranvia Milano-Cinisello Balsamo:0.35
Total track length (km)
170
Total network stops
--
Avg. stop net distance (km)
--
Type
steel wheels
Current/Voltage
600 V DC overhead
Type of guide/gauge
1445 mm gauge rails
Vehicles builder
BREDA/CARMINATI TOSELLI/OFFICINE MECCANICHE LODIGIANE/OFFICINE MECCANICHE REGGIANE/OFFICINE ELETTROFERROVIARIE TALLERO,OFFICINE MECCANICHE DELLA STANGA/BREDA,FIAT FERROVIARIA/OFFICINE MECCANICHE DELLA STANGA,ADTRANZ,ANSALDO BREDA
Model
serie 1500,serie 4600,serie 4700,serie 4900,Eurotram,Sirio
Operator
AZIENDA TRASPORTI MILANESI (ATM)
(last modified February 19, 2017 )
this map is shown here at its maximum resolution (800 x 1312)


lrt-tram - milan; By Friedrichstrasse (openstreetmap.org) [ODbL (http://opendatacommons.org/licenses/odbl/1.0/) or CC BY-SA 2.0 (http://creativecommons.org/licenses/by-sa/2.0)], via Wikimedia Commons
