DESCRIPTION
Munich U-Bahn system opened in 1971 (U6: Kieferngarten-Goetheplatz); it currently consists in 6 lines (which can be divided in 3 groups: U1/U2, U3/U6, U4/U5 each one with part of the track in common) that run almost totally underground (except for 2 short teminal segments of U5 and U6).
U6 opened in 1971 (Kieferngarten-Goetheplatz) and it was extended in 1975, 1978 and 1983; it connects Garching (outside Munich, northern end) to Klinikum Glosshadern, partly running along existing tunnels formerly used by trams. U3 started its service in 1972 (Munchner Freiheit-Olympiazentrum) in occasion of the Olympic Games; it was extended in 1975, 1978, 1989, 1991, 2007 and 2010. U3 currently goes from the Olympic area to Furstenried West. U6 and U3 share a common section (Munchen Freiheit-Implerstrasse).
U2 opened in 1980 (Scheidplatz-Neuperlach Sud) and it was extended in 1993, 1996 and 1999; it currently runs from Felmoching (northern terminal and railways interchange point to the airport) to Messestadt Ost. U1 opened in 1983 (Central Station-Rotkreuzplatz) and it was extended in 1997, 1998, 2003 and 2004; U1 currently runs from Olympia-Einkaufs-zentrum to Mangfallplatz. U1 and U2 share a common section (Munchen Hauptbahnhof-Kolumbusplatz).
U4/U5 opened in 1984 (common section: Westendstrasse-Karlsplatz). U4 was extended in 1986 and 1988; it currently runs from Westens Strasse to Arabellapark. U5 was extended in 1988; it currently runs from Laimer Platz to Neuperlach-Sud. U4 and U5 share a common section (Westendstrasse-Max Weber Platz).
(last modified February 19, 2017 )
HISTORY
datesection nameline
28-05-1983Central Station-RotkreuzplatzU1
08-11-1997Kolumbusplatz-MangfallplatzU1
23-05-1998Rotkreuzplatz-WestfriedhofU1
18-10-2003Westfriedhof-Georgb Brauchle RingU1
31-10-2004Georg Brauchle Ring-Olympia EinkaufszentrumU1
18-10-1980Scheidplatz-Neuperlach SudU2
20-11-1993Scheidplatz-DulferstrasseU2
26-10-1996Dulferstrasse-FeldmochingU2
29-05-1999Innsbrucker Ring-Messestadtn OstU2
08-05-1972Munchner Freiheit-OlympiazentrumU3
22-11-1975Goetheplatz-HarrasU3
28-05-1978Poccistrasse stopU3
28-10-1989Implerstrasse-Forstenrieder AlleeU3
01-06-1991Forstenrieder Allee-Furstenried WestU3
28-10-2007Olympiazentrum-Olympia EinkaufszentrumU3
11-12-2010Olympia Einkaufszentrum-MoosachU3
198403010WestendstraSSe-KarlsplatzU4
198403010 tunnel link to U3/U6'>WestendstraSSe-Karlsplatz -> tunnel link to U3/U6U4
01-03-1986Karlsplatz-OdeonsplatzU4
24-03-1988Westendstrasse-Laimer PlatzU4
27-10-1988Max Weber Platz-ArabellaparkU4
10-03-1984 tunnel link to U3/U6'>WestendstraSSe-Karlsplatz -> tunnel link to U3/U6U5
24-03-1988Westendstrasse-Laimer PlatzU5
27-10-1988Odeonsplatz-Innsbrucker RingU5
19-10-1971Kieferngarten-GoetheplatzU6
22-11-1975Goetheplatz-HarrasU6
28-05-1978Poccistrasse stopU6
198301416Harras-HolzapfelkreuthU6
01-03-1986Karlsplatz-OdeonsplatzU5
22-05-1993Holzapfelkreuth-Klinikum Grosshadern/Grosshadern Clinical CentreU6
30-06-1994Kieferngarten-FrottmaningU6
28-10-1995Frottmaning-Garching HochbruckU6
14-10-2006Garching Hochbruck-Garching ForschungszentrumU6
11-12-2011Westfriedhof-Neuperlach ZentrumU7
14-12-2013Sendlinger Tor-OlympiazentrumU8
(last modified February 19, 2017 )
TECHNICAL DATA
Single line length (Km)
U1:12.2
U2:24.4
U3:21.4
U4:9.2
U5:15.4
U6:27.4
U7:13
U8:6.5
Single line stops
U1:14
U2:27
U3:25
U4:13
U5:18
U6:26
U7:17
U8:9
Single line avg. distance (km)
U1:0.9
U2:0.9
U3:0.9
U4:0.7
U5:0.9
U6:1.1
U7:0.8
U8:0.9
Total track length (km)
103.1
Total network stops
100
Avg. stop net distance (km)
1.05
Type
steel wheels
Current/Voltage
750 V DC from third rail
Guide/gauge
standard gauge rails (1435 mm)
Vehicles builder
O&K, MANN, RATHGEBER, BOMBARDIER, SIEMENS
Model
class A (O&K, Mann, Rathgeber, WMD),class (DWA, Mann, MBB),class C (ADTranz, Siemens)
Operator
MUNCHNER VERKEHRGESELLSHAFT MBH (MVG)
(last modified February 19, 2017 )
This image is shown smaller (800 x 559 pixels) than its maximum size (1500 x 1049 pixels)
Please click on the map to enlarge it to its maximum size


metro - munich; By Maximilian Dorrbecker (Chumwa) (Own work) [CC BY-SA 2.5 (http://creativecommons.org/licenses/by-sa/2.5)], via Wikimedia Commons
